1.5mm

Front

Glass

Cutting

Edge

Spraying

Anti

Glare

Print

Control

Device

AG

Glass

- High-Quality Glass Material: Made from clear glass, soda-lime glass, or low iron glass, this product ensures excellent clarity and transparency, allowing for optimal light transmission and minimal distortion.

- Advanced Anti-Glare Coating: Equipped with a specialized anti-glare coating, this glass reduces reflections and glare, providing enhanced visibility and clarity in various lighting conditions.



Technical Specifications:

- Material: Clear Glass/Soda-lime Glass/Low Iron Glass

- Transmittance: 85%

- Compression Strength (CS): ≥650Mpa

- Depth of Layer (DOL): ≥28μm



Manufacturing Process:

1. Laser Cutting: Utilizing precise laser cutting technology, the glass is cut to the desired size and shape with accuracy and consistency.

2. Smooth Edge: Edges are meticulously polished to achieve a smooth finish, enhancing safety and aesthetics.

3. Physical Tempered: Through a specialized physical tempering process, the glass is reinforced to increase its durability and resistance to impact, ensuring long-lasting performance.

4. Silk Screen Printing: Intricate designs or patterns can be silk-screened onto the glass surface, adding a personalized touch and customization options tailored to your specific requirements.

5. AG Coating Application: An advanced anti-glare coating is applied to the glass surface, reducing reflections and glare, providing enhanced visibility and clarity, particularly in bright environments.



Applications:

- Electronic displays and touchscreens

- Appliance control panels and touchscreens

- Retail displays and signage

- Architectural glazing

- Interior design elements such as partitions and doors



For inquiries or custom orders, please feel free to contact us. Our team is dedicated to providing tailored solutions to meet your glass product needs.

Step 1: PE film coating(Normally) / paper(For sea shipment prevent wet).

Step 2: Kraft paper for fixation.

Step 3: Carton for glass safety protection.

Step 4: Custom make plywood case with hinge for custom(fumigation + convenient inspection) convenience.

Step 5: Packing strap for further fixation.

Port: Shenzhen or Hongkong
